CAT6-COPPER UTP

Premium CAT6 UTP Network cable utilizing Solid Copper cores and 'Spline' separator for enhanced durability and electrical performance characteristics. Used in high Speed Gigabit Ethernet applications. Grey, 305M Box.

CAT6 Copper UTP Network cable, 305m ‘easy pull’ box.

CAT6 core conductors with PVC Jacket & plastic ‘Spline’ separator

Features:

CAT6-COPPER  U/UTP (With Spline) High Speed Networking Cable.

Premium quality CAT6 multi-twisted pair high performance networking cable used in Gigabit Ethernet, HDTV, HD CCTV Video transmission, VOIP and other applications.

The cable consists of 4 x unshielded twisted pairs 23AWG. with insulated Solid Copper conductors and central 'Spline' to prevent Cross Talk. Comes with PVC outer jacket in Grey.

Designed to conform to the  ANSI/TIA/EIA 568C Standards.

Supplied on 305M reel (Boxed)

  • Application: Networking or CCTV video

  • 4 pair Solid Copper conductors.

  • 23AWG core diameter

  • U/UTP Unshielded Twisted Pairs

  • HDPE Polyethylene Insulation 1.0mm

  • Central Spline to prevent Cross Talk

  • PVC Polyvinyl Chloride Sheath 6.3 mm

  • Sheath colour : GREY

  • Minimum, bending radius 5 x O/D.

  • Frequency range in excess of 250Mhz

  • current rating 0.75 Amps

  • CE & RoHS compliant

  • ANSI  TIA/EIA 568C.2 compliant

  • temp -20c to +60c

  • Boxed 305M Reel
