CAT5E-COPPER/FTP Foil Screened

CAT5e Networking cable, 4 x twisted pairs with 100% solid copper core conductors and Aluminium Foil Screening (FTP), PVC outer Sheath in Grey, 305m.

CAT5E FTP, Solid copper cores, 305M Box

CAT5E FTP 'aluminium Foil screened' with Grey PVC Sheath

Features:

CAT5E-COPPER/FTP  Network Cable

A high quality multi-twisted pair, outer Foil screened, high signal integrity cable used in high speed Networking, CCTV Video, VOIP and other data transmission applications.

The cable consists of 4 twisted pair Solid Copper conductors, with Aluminium foil shielding and PVC outer jacket in Grey.

Designed to conform to the  ANSI/EIA/TIA 568C.2 ISO/IEC 11801 Standards.

Supplied on 305M reel (Boxed)

  • Application:  Networking cable

  • 4 x Twisted Pairs with common foil shield

  • Aluminium Foil shield FTP (F/UTP)

  • 0.50mm conductors, 24 AWG

  • 100% Solid Copper conductors

  • HDPE Polyethylene Insulation 1.0mm

  • PVC (Polyvinyl Chloride) Sheath

  • Sheath colour : GREY

  • Jacket overall diameter 6.2 mm

  • Minimum, bending radius 5 x O.D

  • Frequency range 100Mhz

  • current rating 0.6 Amps

  • CE & RoHS compliant

  • ANSI  EIA/TIA 568C.2 compliant

  • temp -20 to +60c

  • Boxed 305M Reel


Cable Specification
