CAT5E-COPPER-FTP/EXT

CAT5e Outdoor 'Duct grade' Networking cable, 4 twisted pair 100% Solid Copper conductors with Foil screening (FTP) & weather resistant PE Sheath in black. 305m.

p

CAT5E-FTP external Duct Grade, 305M Box

CAT5E FTP External 'Duct Grade' in Black

Features:

CAT5E-Copper-FTP/EXT  Outdoor 'Duct Grade' Network Cable

A multi-twisted pair, Foil screened, high signal integrity cable used in high speed Computer Networking, CCTV Video and data transmission applications where outdoor weather  and corrosion resistance are required.

The cable consists of 4 xTwisted pair solid copper conductors with Aluminium foil outer shield and 'Duct Grade' Polyethylene (PE) Black outer jacket..

Designed to conform to the ANSI EIA/TIA 568C.2, ISO/IEC 11801 Standards.

Supplied on 305M reel (Boxed)

  • Application: Outdoor Network cable

  • 4 pair FTP (shielded Twisted Pair)

  • Aluminium Foil shield (U/FTP)

  • 0.50mm 100% Solid Copper conductors, 24AWG

  • HDPE Polyethylene Insulation 1.0mm

  • PE Polyethylene Sheath 'Duct Grade'

  • Sheath colour : BLACK

  • Jacket overall diameter 5.5 mm

  • Minimum, bending radius 4 x O.D

  • Frequency range 100Mhz

  • current rating 0.6 Amps

  • CE & RoHS compliant

  • ANSI  EIA/TIA 568C.2 compliant

  • temp -20 to +60c

  • Boxed 305M Reel


 Cable Specification
